Medium fibre-count MPO trunk assemblies with 36 to 144 fibres. Enables fast, large-scale deployment with reduced labour and minimal installation overhead.

Supports 36 to 144 fibres per trunk
Available with MPO-8, MPO-12 or MPO-24 connectors
Factory terminated and 100% IL/RL tested
LSZH outer jacket with CPR options
Ideal for zone distribution, and backbone extensions
Simplifies installation and reduces pathway usage

Category: Optical Cable Assemblies, MPO Trunks and Fanouts

ENQUIRE NOW

Engineered to Outperform

Delivered with Certainty

Procurement Made Simple

Rapid Deployment Ready

Ready To Scale

Compliance Assured

Medium Fibre Count MPO trunk cables are engineered for high‑density backbone, cross‑connect, and patching deployments. Available from 36 to 144 fibres, they deliver a scalable, space-efficient solution across enterprise data centres, edge environments, and access-layer switching.

Pre‑terminated with MPO-8, MPO‑12 or MPO‑24 connectors, these assemblies are designed to maximise port utilisation and reduce installation time in structured cabling systems. Each unit is factory tested for low insertion loss and high return loss, ensuring reliable optical performance in demanding applications.

Sheath options include LSZH and CPR ratings to meet diverse compliance and installation requirements. These medium fibre‑count trunks enable rapid deployment of large core capacities in a single pull—streamlining installation and reducing on‑site labour in core, horizontal, and distribution layers.

General
Connector Types	MPO-8, MPO-12, MPO-24 (male or female, pinned or unpinned)
Fibre Count Range	36 to 144 fibres per trunk
Polarity Options	Type A, B, C
Cable Specification
Jacket Material	Low Smoke Zero Halogen (LSZH)
Cable Diameter	3mm
Fibre Type	Single-mode OS2 Multimode OM3/OM4/OM5
Insertion Loss	≤0.35 dB per connector
Return Loss	≥60 dB (SM); ≥30 dB (MM)
Operating Temperature	-20°C to +70°C
Compliance	TIA/EIA-568, IEC 61754-7, FOCIS-5, RoHS, REACH

Fibre Optic Assembly, Single-mode (G.657.A1), 48F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-S7-48-MPOF-MPOF-A-3M	3
MT-S7-48-MPOF-MPOF-A-5M	5
MT-S7-48-MPOF-MPOF-A-10M	10
MT-S7-48-MPOF-MPOF-A-15M	15
MT-S7-48-MPOF-MPOF-A-20M	20
MT-S7-48-MPOF-MPOF-A-25M	25
MT-S7-48-MPOF-MPOF-A-30M	30
MT-S7-48-MPOF-MPOF-A-35M	35
MT-S7-48-MPOF-MPOF-A-40M	40
MT-S7-48-MPOF-MPOF-A-45M	45
MT-S7-48-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Single-mode (G.657.A1), 48F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-S7-48-MPOF-MPOF-B-3M	3
MT-S7-48-MPOF-MPOF-B-5M	5
MT-S7-48-MPOF-MPOF-B-10M	10
MT-S7-48-MPOF-MPOF-B-15M	15
MT-S7-48-MPOF-MPOF-B-20M	20
MT-S7-48-MPOF-MPOF-B-25M	25
MT-S7-48-MPOF-MPOF-B-30M	30
MT-S7-48-MPOF-MPOF-B-35M	35
MT-S7-48-MPOF-MPOF-B-40M	40
MT-S7-48-MPOF-MPOF-B-45M	45
MT-S7-48-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Single-mode (G.657.A1), 48F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-S7-48-MPOF-MPOF-C-3M	3
MT-S7-48-MPOF-MPOF-C-5M	5
MT-S7-48-MPOF-MPOF-C-10M	10
MT-S7-48-MPOF-MPOF-C-15M	15
MT-S7-48-MPOF-MPOF-C-20M	20
MT-S7-48-MPOF-MPOF-C-25M	25
MT-S7-48-MPOF-MPOF-C-30M	30
MT-S7-48-MPOF-MPOF-C-35M	35
MT-S7-48-MPOF-MPOF-C-40M	40
MT-S7-48-MPOF-MPOF-C-45M	45
MT-S7-48-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Single-mode (G.657.A1), 72F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-S7-72-MPOF-MPOF-A-3M	3
MT-S7-72-MPOF-MPOF-A-5M	5
MT-S7-72-MPOF-MPOF-A-10M	10
MT-S7-72-MPOF-MPOF-A-15M	15
MT-S7-72-MPOF-MPOF-A-20M	20
MT-S7-72-MPOF-MPOF-A-25M	25
MT-S7-72-MPOF-MPOF-A-30M	30
MT-S7-72-MPOF-MPOF-A-35M	35
MT-S7-72-MPOF-MPOF-A-40M	40
MT-S7-72-MPOF-MPOF-A-45M	45
MT-S7-72-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Single-mode (G.657.A1), 72F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-S7-72-MPOF-MPOF-B-3M	3
MT-S7-72-MPOF-MPOF-B-5M	5
MT-S7-72-MPOF-MPOF-B-10M	10
MT-S7-72-MPOF-MPOF-B-15M	15
MT-S7-72-MPOF-MPOF-B-20M	20
MT-S7-72-MPOF-MPOF-B-25M	25
MT-S7-72-MPOF-MPOF-B-30M	30
MT-S7-72-MPOF-MPOF-B-35M	35
MT-S7-72-MPOF-MPOF-B-40M	40
MT-S7-72-MPOF-MPOF-B-45M	45
MT-S7-72-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Single-mode (G.657.A1), 72F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-S7-72-MPOF-MPOF-C-3M	3
MT-S7-72-MPOF-MPOF-C-5M	5
MT-S7-72-MPOF-MPOF-C-10M	10
MT-S7-72-MPOF-MPOF-C-15M	15
MT-S7-72-MPOF-MPOF-C-20M	20
MT-S7-72-MPOF-MPOF-C-25M	25
MT-S7-72-MPOF-MPOF-C-30M	30
MT-S7-72-MPOF-MPOF-C-35M	35
MT-S7-72-MPOF-MPOF-C-40M	40
MT-S7-72-MPOF-MPOF-C-45M	45
MT-S7-72-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 48F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M3-48-MPOF-MPOF-A-3M	3
MT-M3-48-MPOF-MPOF-A-5M	5
MT-M3-48-MPOF-MPOF-A-10M	10
MT-M3-48-MPOF-MPOF-A-15M	15
MT-M3-48-MPOF-MPOF-A-20M	20
MT-M3-48-MPOF-MPOF-A-25M	25
MT-M3-48-MPOF-MPOF-A-30M	30
MT-M3-48-MPOF-MPOF-A-35M	35
MT-M3-48-MPOF-MPOF-A-40M	40
MT-M3-48-MPOF-MPOF-A-45M	45
MT-M3-48-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 48F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M3-48-MPOF-MPOF-B-3M	3
MT-M3-48-MPOF-MPOF-B-5M	5
MT-M3-48-MPOF-MPOF-B-10M	10
MT-M3-48-MPOF-MPOF-B-15M	15
MT-M3-48-MPOF-MPOF-B-20M	20
MT-M3-48-MPOF-MPOF-B-25M	25
MT-M3-48-MPOF-MPOF-B-30M	30
MT-M3-48-MPOF-MPOF-B-35M	35
MT-M3-48-MPOF-MPOF-B-40M	40
MT-M3-48-MPOF-MPOF-B-45M	45
MT-M3-48-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 48F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M3-48-MPOF-MPOF-C-3M	3
MT-M3-48-MPOF-MPOF-C-5M	5
MT-M3-48-MPOF-MPOF-C-10M	10
MT-M3-48-MPOF-MPOF-C-15M	15
MT-M3-48-MPOF-MPOF-C-20M	20
MT-M3-48-MPOF-MPOF-C-25M	25
MT-M3-48-MPOF-MPOF-C-30M	30
MT-M3-48-MPOF-MPOF-C-35M	35
MT-M3-48-MPOF-MPOF-C-40M	40
MT-M3-48-MPOF-MPOF-C-45M	45
MT-M3-48-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 72F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M3-72-MPOF-MPOF-A-3M	3
MT-M3-72-MPOF-MPOF-A-5M	5
MT-M3-72-MPOF-MPOF-A-10M	10
MT-M3-72-MPOF-MPOF-A-15M	15
MT-M3-72-MPOF-MPOF-A-20M	20
MT-M3-72-MPOF-MPOF-A-25M	25
MT-M3-72-MPOF-MPOF-A-30M	30
MT-M3-72-MPOF-MPOF-A-35M	35
MT-M3-72-MPOF-MPOF-A-40M	40
MT-M3-72-MPOF-MPOF-A-45M	45
MT-M3-72-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 72F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M3-72-MPOF-MPOF-B-3M	3
MT-M3-72-MPOF-MPOF-B-5M	5
MT-M3-72-MPOF-MPOF-B-10M	10
MT-M3-72-MPOF-MPOF-B-15M	15
MT-M3-72-MPOF-MPOF-B-20M	20
MT-M3-72-MPOF-MPOF-B-25M	25
MT-M3-72-MPOF-MPOF-B-30M	30
MT-M3-72-MPOF-MPOF-B-35M	35
MT-M3-72-MPOF-MPOF-B-40M	40
MT-M3-72-MPOF-MPOF-B-45M	45
MT-M3-72-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM3), 72F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M3-72-MPOF-MPOF-C-3M	3
MT-M3-72-MPOF-MPOF-C-5M	5
MT-M3-72-MPOF-MPOF-C-10M	10
MT-M3-72-MPOF-MPOF-C-15M	15
MT-M3-72-MPOF-MPOF-C-20M	20
MT-M3-72-MPOF-MPOF-C-25M	25
MT-M3-72-MPOF-MPOF-C-30M	30
MT-M3-72-MPOF-MPOF-C-35M	35
MT-M3-72-MPOF-MPOF-C-40M	40
MT-M3-72-MPOF-MPOF-C-45M	45
MT-M3-72-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 48F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M4-48-MPOF-MPOF-A-3M	3
MT-M4-48-MPOF-MPOF-A-5M	5
MT-M4-48-MPOF-MPOF-A-10M	10
MT-M4-48-MPOF-MPOF-A-15M	15
MT-M4-48-MPOF-MPOF-A-20M	20
MT-M4-48-MPOF-MPOF-A-25M	25
MT-M4-48-MPOF-MPOF-A-30M	30
MT-M4-48-MPOF-MPOF-A-35M	35
MT-M4-48-MPOF-MPOF-A-40M	40
MT-M4-48-MPOF-MPOF-A-45M	45
MT-M4-48-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 48F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M4-48-MPOF-MPOF-B-3M	3
MT-M4-48-MPOF-MPOF-B-5M	5
MT-M4-48-MPOF-MPOF-B-10M	10
MT-M4-48-MPOF-MPOF-B-15M	15
MT-M4-48-MPOF-MPOF-B-20M	20
MT-M4-48-MPOF-MPOF-B-25M	25
MT-M4-48-MPOF-MPOF-B-30M	30
MT-M4-48-MPOF-MPOF-B-35M	35
MT-M4-48-MPOF-MPOF-B-40M	40
MT-M4-48-MPOF-MPOF-B-45M	45
MT-M4-48-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 48F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M4-48-MPOF-MPOF-C-3M	3
MT-M4-48-MPOF-MPOF-C-5M	5
MT-M4-48-MPOF-MPOF-C-10M	10
MT-M4-48-MPOF-MPOF-C-15M	15
MT-M4-48-MPOF-MPOF-C-20M	20
MT-M4-48-MPOF-MPOF-C-25M	25
MT-M4-48-MPOF-MPOF-C-30M	30
MT-M4-48-MPOF-MPOF-C-35M	35
MT-M4-48-MPOF-MPOF-C-40M	40
MT-M4-48-MPOF-MPOF-C-45M	45
MT-M4-48-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 72F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M4-72-MPOF-MPOF-A-3M	3
MT-M4-72-MPOF-MPOF-A-5M	5
MT-M4-72-MPOF-MPOF-A-10M	10
MT-M4-72-MPOF-MPOF-A-15M	15
MT-M4-72-MPOF-MPOF-A-20M	20
MT-M4-72-MPOF-MPOF-A-25M	25
MT-M4-72-MPOF-MPOF-A-30M	30
MT-M4-72-MPOF-MPOF-A-35M	35
MT-M4-72-MPOF-MPOF-A-40M	40
MT-M4-72-MPOF-MPOF-A-45M	45
MT-M4-72-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 72F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M4-72-MPOF-MPOF-B-3M	3
MT-M4-72-MPOF-MPOF-B-5M	5
MT-M4-72-MPOF-MPOF-B-10M	10
MT-M4-72-MPOF-MPOF-B-15M	15
MT-M4-72-MPOF-MPOF-B-20M	20
MT-M4-72-MPOF-MPOF-B-25M	25
MT-M4-72-MPOF-MPOF-B-30M	30
MT-M4-72-MPOF-MPOF-B-35M	35
MT-M4-72-MPOF-MPOF-B-40M	40
MT-M4-72-MPOF-MPOF-B-45M	45
MT-M4-72-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM4), 72F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M4-72-MPOF-MPOF-C-3M	3
MT-M4-72-MPOF-MPOF-C-5M	5
MT-M4-72-MPOF-MPOF-C-10M	10
MT-M4-72-MPOF-MPOF-C-15M	15
MT-M4-72-MPOF-MPOF-C-20M	20
MT-M4-72-MPOF-MPOF-C-25M	25
MT-M4-72-MPOF-MPOF-C-30M	30
MT-M4-72-MPOF-MPOF-C-35M	35
MT-M4-72-MPOF-MPOF-C-40M	40
MT-M4-72-MPOF-MPOF-C-45M	45
MT-M4-72-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 48F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M5-48-MPOF-MPOF-A-3M	3
MT-M5-48-MPOF-MPOF-A-5M	5
MT-M5-48-MPOF-MPOF-A-10M	10
MT-M5-48-MPOF-MPOF-A-15M	15
MT-M5-48-MPOF-MPOF-A-20M	20
MT-M5-48-MPOF-MPOF-A-25M	25
MT-M5-48-MPOF-MPOF-A-30M	30
MT-M5-48-MPOF-MPOF-A-35M	35
MT-M5-48-MPOF-MPOF-A-40M	40
MT-M5-48-MPOF-MPOF-A-45M	45
MT-M5-48-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 48F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M5-48-MPOF-MPOF-B-3M	3
MT-M5-48-MPOF-MPOF-B-5M	5
MT-M5-48-MPOF-MPOF-B-10M	10
MT-M5-48-MPOF-MPOF-B-15M	15
MT-M5-48-MPOF-MPOF-B-20M	20
MT-M5-48-MPOF-MPOF-B-25M	25
MT-M5-48-MPOF-MPOF-B-30M	30
MT-M5-48-MPOF-MPOF-B-35M	35
MT-M5-48-MPOF-MPOF-B-40M	40
MT-M5-48-MPOF-MPOF-B-45M	45
MT-M5-48-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 48F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M5-48-MPOF-MPOF-C-3M	3
MT-M5-48-MPOF-MPOF-C-5M	5
MT-M5-48-MPOF-MPOF-C-10M	10
MT-M5-48-MPOF-MPOF-C-15M	15
MT-M5-48-MPOF-MPOF-C-20M	20
MT-M5-48-MPOF-MPOF-C-25M	25
MT-M5-48-MPOF-MPOF-C-30M	30
MT-M5-48-MPOF-MPOF-C-35M	35
MT-M5-48-MPOF-MPOF-C-40M	40
MT-M5-48-MPOF-MPOF-C-45M	45
MT-M5-48-MPOF-MPOF-C-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 72F, MPO-12 to MPO-12, Polarity A, LSZH
Part Number	Length (m)
MT-M5-72-MPOF-MPOF-A-3M	3
MT-M5-72-MPOF-MPOF-A-5M	5
MT-M5-72-MPOF-MPOF-A-10M	10
MT-M5-72-MPOF-MPOF-A-15M	15
MT-M5-72-MPOF-MPOF-A-20M	20
MT-M5-72-MPOF-MPOF-A-25M	25
MT-M5-72-MPOF-MPOF-A-30M	30
MT-M5-72-MPOF-MPOF-A-35M	35
MT-M5-72-MPOF-MPOF-A-40M	40
MT-M5-72-MPOF-MPOF-A-45M	45
MT-M5-72-MPOF-MPOF-A-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 72F, MPO-12 to MPO-12, Polarity B, LSZH
Part Number	Length (m)
MT-M5-72-MPOF-MPOF-B-3M	3
MT-M5-72-MPOF-MPOF-B-5M	5
MT-M5-72-MPOF-MPOF-B-10M	10
MT-M5-72-MPOF-MPOF-B-15M	15
MT-M5-72-MPOF-MPOF-B-20M	20
MT-M5-72-MPOF-MPOF-B-25M	25
MT-M5-72-MPOF-MPOF-B-30M	30
MT-M5-72-MPOF-MPOF-B-35M	35
MT-M5-72-MPOF-MPOF-B-40M	40
MT-M5-72-MPOF-MPOF-B-45M	45
MT-M5-72-MPOF-MPOF-B-50M	50

Fibre Optic Assembly, Multi-mode (OM5), 72F, MPO-12 to MPO-12, Polarity C, LSZH
Part Number	Length (m)
MT-M5-72-MPOF-MPOF-C-3M	3
MT-M5-72-MPOF-MPOF-C-5M	5
MT-M5-72-MPOF-MPOF-C-10M	10
MT-M5-72-MPOF-MPOF-C-15M	15
MT-M5-72-MPOF-MPOF-C-20M	20
MT-M5-72-MPOF-MPOF-C-25M	25
MT-M5-72-MPOF-MPOF-C-30M	30
MT-M5-72-MPOF-MPOF-C-35M	35
MT-M5-72-MPOF-MPOF-C-40M	40
MT-M5-72-MPOF-MPOF-C-45M	45
MT-M5-72-MPOF-MPOF-C-50M	50
