EasyDROP™ Wajen Drop Cable ne m, toneable ko dielectric dielectric kebul na dielectric da ke nuna fasahar igiyar tsakiya don sassauƙan kwatance.
- 900μm core suits [FieldFIT ™ haši] (http://localhost:1313/products/connectivity-accessories/field-connectors/fieldfit-connectors/)
- Ƙarshen igiya na 2mm yana ba da damar kewaya cikin gida
- LSZH jaket lafiya don amfanin cikin gida
- An toshe ruwa don amincin waje
- An ƙididdige shi don shigarwar iska, bututun ruwa da binne
- Membobin ƙarfin FRP guda biyu don juriya
- Lebur bayanan martaba sun dace da matsuguni
An Ƙera Don Zarcewa
An Bayar da Tabbatacce
Sayarwa Ta Zama Sauƙi
Shirye Don Gaggauta Tura
Shirye Don Faɗaɗawa
Bin Ka’ida Tabbas
An gina shi don saurin tura aiki mai sauƙi a cikin gidaje guda ɗaya da na nesa, wannan kebul ɗin faɗuwar faɗuwar ruwa yana haɗe taurin waje tare da sassauci na cikin gida.
Gine-ginen na biyu-Layer yana da babban kumfa na waje na PE wanda ke tsiri da tsafta don bayyana igiya 2.0 mm LSZH tare da madaidaicin μm 900, shirye don ƙarewar filin kai tsaye ta amfani da ScaleFibre FieldFit™ Connectors .
Akwai shi cikin nau'in dielectric (kyauta daga abubuwa na ƙarfe), yana goyan bayan shigarwar iska, bututu, da shigarwar da aka binne kai tsaye. Bayanan martabarsa yana ba da sauƙi don mu'amala da madaidaicin hanya, yayin da ƙirar da aka toshe ruwa yana tabbatar da ingantaccen aiki a cikin yanayi mara kyau.
| Cikakken Bayanin Gina | |
| Ƙididdigar Fiber | 1 fiber |
| Nau'in Fiber | Single-yanayin (OS2), ITU-T G.657.A1 |
| Kayan Jaket na waje | Polyethylene (PE) |
| Kayan Jaket na Igiya | Halogen mara ƙarancin hayaki (LSZH) |
| Ƙarfafa Membobi | Zaɓuɓɓukan Dielectric ko toneable (jan karfe). |
| Girman Kebul | |
| Diamita Mafi Girma | 8.2mm x 4.5 mm |
| Nauyi | 40.5 kg/km |
| Halayen Injini | |
| Matsakaicin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙashin Ƙarƙwara | 1.35 kN |
| Max Tensile (Lokaci mai tsawo) | 400 N |
| Crush Resistance | 1000 N / 10 cm |
| Lanƙwasa Radius (Shigarwa) | ≥20 × OD |
| Lanƙwasa Radius (A tsaye) | ≥10 × OD |
| Halayen Muhalli | |
| Zazzabi - Shigarwa | -10°C zuwa +60°C |
| Zazzabi - Aiki | -20°C zuwa +70°C |
| Zazzabi - Adanawa | -20°C zuwa +70°C |
| Biyayya | |
| Matsayi | IEC 60794-1-2, IEC 60794-3, AS/CA S008, ITU-T G.657.A1 |
| RoHS3 mai yarda | Ee |
| EasyDROP™ 1F Bambance-bambance | |
| Saukewa: C-FDC-S7-1-P | EasyDROP™ Waje Flat Drop Cable tare da 2mm Igiya, Single Mode (G.657.A1), Simplex |
| Saukewa: C-FDT-S7-1-P | EasyDROP™ Wajen Toneable Flat Drop Cable tare da Igiyar 2mm, Yanayin Single (G.657.A1), Simplex |
