Ƙananan pigtails masu ribbon-da-za-a-iya-naɗewa a cikin G.657.A1 single‑mode — haɗa fiber 12 a gida ɗaya kuma rage sararin tire.
- Siffar ribbon mai sauƙi tana naɗewa don sauƙin jagoranci sannan ta miƙe don haɗawa mai yawa
- Haɗa 12 lokaci guda, har sau 8 fiye da fiber guda ɗaya
- LC, SC, da MPO da aka goge a masana’anta
- Kammalawa na UPC da APC don daidaita aiki
- An gwada su a masana’anta don asarar shiga da dawowa a kowane core
An Ƙera Don Zarcewa
An Bayar da Tabbatacce
Sayarwa Ta Zama Sauƙi
Shirye Don Gaggauta Tura
Shirye Don Faɗaɗawa
Bin Ka’ida Tabbas
ScaleFibre Flexible_Ribbon Optical_Pigtails suna haɗa ingancin tsarin ribbon mai yawan lambobi tare da sauƙin sarrafa fiber marasa haɗi. Tsarin da za a iya naɗewa yana komawa zuwa ɗan kunshin matse don jagoranci mara toshewa, sannan ya buɗe zuwa ribbon mai lebur don haɗawa ta hanyar yawan guga fiber 12 guda ɗaya.
Kowace haɗuwa an riga an kammala ta a masana'anta kuma an gwada ta 100% ta hanyar gani, wanda ke tabbatar da ƙarancin asarar shiga da babban asarar dawowa. Zaɓi LC, SC ko MPO masu haɗawa a cikin UPC ko APC goge don dacewa da tsarin haɗin ku. Cikakke ga cibiyoyin bayanai na hyperscale, 5G front‑haul, da gine-gine masu yawa na ODF inda kowane milimita na sararin tire yana da mahimmanci.
| Bayyanawa na Fasaha | |
| Nau'in Ribbon | Ribbon mai naɗewa / mai sauƙi, fiber 250_µm |
| Adadin Fiber | 12F |
| Matsayin Fiber | Single‑mode G.657.A1 |
| Nau'in Masu Haɗawa | LC, SC, MPO (Mace ko Namiji) |
| Zaɓuɓɓukan Goge | UPC ko APC |
| Tsari | Ƙarshen da ba a kammala ba an gabatar da shi azaman ribbon mai shirye-shiryen haɗawa mai yawa |
| Matsakaicin Tsayi | mita 2 |
| Asarar Shiga | ≤ 0.12 dB (Matsakaici), ≤ 0.25 dB (Max) - IEC Grade B |
| Asarar Dawowa | ≥ 55 dB (UPC), ≥ 65 dB (APC) - Grade 1 |
| Zazzabi na Aiki | –20_°C zuwa_+70_°C |
| Ka'idoji Masu Dace | IEC_61754 / 61755, TIA/EIA‑568, RoHS, REACH |
| Standard 250µm Flexible_Ribbon Pigtails | |
| PT-S7-FR-LC-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, LC/UPC, mita 2, fakiti 1, Mai launi |
| PT-S7-FR-LCA-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, LC/APC, mita 2, fakiti 1, Mai launi |
| PT-S7-FR-SC-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, SC/UPC, mita 2, fakiti 1, Mai launi |
| PT-S7-FR-SCA-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, SC/APC, mita 2, fakiti 1, Mai launi |
| MPO 3mm Cord 250µm Flexible_Ribbon Pigtails | |
| PT-S7-FR3-MPOF-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, igiyar 3mm, MPO(12F)-Female, mita 2, fakiti 1, Mai launi |
| PT-S7-FR3-MPOM-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, igiyar 3mm, MPO(12F)-Male, mita 2, fakiti 1, Mai launi |
